Transmission System Case

Transmission System Case

The gear box housing is used as a rigid structural frame for transmission and industrial equipment. The gear box housing is available in Q235 carbon steel, square steel, or ductile iron and is precision machined after welding or casting. Stress-relief treatment and correction are carried out to control the installation plane flatness to ≤0.1 mm/m. The frame can be used for automated conveyor lines, heavy-duty power units, and other equipment where stable structural support is required.
Send Inquiry
Description

Product Description



The gear box housing is used as a rigid structural frame for transmission and industrial equipment. The gear box housing is available in Q235 carbon steel, square steel, or ductile iron and is precision machined after welding or casting. Stress-relief treatment and correction are carried out to control the installation plane flatness to ≤0.1 mm/m. The frame can be used for automated conveyor lines, heavy-duty power units, and other equipment where stable structural support is required.

product-795-789

Production is carried out at our 27,000-square-meter facility in Hubei. The case includes machined bearing seats and mounting faces, with machining supported by 40+ CNC units. Each finished case is checked before shipment. Depending on the project requirements, we can also provide exterior powder coating and customized mounting hole patterns. We have experience supplying enterprises including Sany and can support EXW, FOB, and DDP terms. Our production team follows the order from pre-sales communication through production and delivery.

product-797-759





Product Parameters



Parameter

Value

Material

Q235 Carbon Steel / Square Steel / Ductile Iron

Structure

Integrated Framework or Chamber Layout

Load Capacity

500 kg ~ 5000 kg (Customizable)

Flatness

≤ 0.1 mm/m (Installation Plane)

Welding Standard

Full Weld, Zero Defects, Stress-Relieved

Surface Finish

Sandblasting + Anti-rust Paint / Powder Coating



Application Fields

Automation

Main support bases for conveyor systems and assembly lines.



Heavy Duty

Structural core of boom lift transmissions for 400t to 2000t cranes.



Power Units

Rigid frames for stationary diesel engines and hydraulic power packs.

product-787-786



Customization Capabilities



We provide non-standard customization based on customer drawings and technical requirements. Dimensions, load reinforcements, and footing types can be adjusted according to the project. Available footing options include bolt-down and adjustable feet. The development cycle for customized frames is generally 20-30 days.



Factory Strength & Quality Control



Our heavy-industry production experience dates back to 1997. Production capacity is arranged according to specific part numbers and order requirements. The facility has 40+ CNC units, including machining centers, as well as 200+ wire-cutting machines. Finished products are subject to a 100% quality check before shipment.



FAQ



Q: Do you accept third-party inspections?

A: Yes. We welcome third-party inspections.

Q: How do you handle shipping damage?

A: We offer free return or replacement for products damaged during shipment.

Q: What is the delivery time?

A: Standard models normally take 10-15 days. Custom frames normally take 20-30 days.
