Agricultural Machinery Gearbox Housing

Agricultural Machinery Gearbox Housing

Field work puts heavy demands on a gearbox. Dust, mud, impact, vibration, and long working hours all place stress on the housing. The Agricultural Machinery Gearbox Housing from Hubei Kangding Machinery Equipment Co., Ltd. is made for these conditions. It is suitable for tractors, harvesters, rotary tillers, and other agricultural machinery. The material options are HT250 or QT450-10 ductile iron, with the housing formed by high-strength precision casting. The rigid structure remains stable under shock and vibration.
Send Inquiry
Description

A Housing That Handles Rough Fields



Field work puts heavy demands on a gearbox. Dust, mud, impact, vibration, and long working hours all place stress on the housing. The Agricultural Machinery Gearbox Housing from Hubei Kangding Machinery Equipment Co., Ltd. is made for these conditions. It is suitable for tractors, harvesters, rotary tillers, and other agricultural machinery. The material options are HT250 or QT450-10 ductile iron, with the housing formed by high-strength precision casting. The rigid structure remains stable under shock and vibration.



Internal flow channels and bearing seats are finish-machined for accurate fitting. This helps the gears run smoothly and keeps operating noise low. The sealing structure helps prevent oil leakage, while the housing provides effective heat dissipation. This Agricultural Machinery Gearbox Housing is suitable for 50–220 hp tractors, combine harvesters, rotary tillers, and medium- to large-size agricultural gearbox assemblies.

product-800-800



Accuracy and Custom Options



The housing can be mounted horizontally or vertically, with flange connection as the standard mounting method. Hole position accuracy reaches IT7–IT8, while flatness is ≤0.05 mm. Lubrication uses splash lubrication together with forced oil channels. The working temperature range is -30°C to 120°C. Surface treatment includes shot blasting and anti-rust primer.



Mounting hole spacing, oil inlet and outlet positions, and flange dimensions can be customized according to the application. The factory has more than 200 wire-cutting machines, over 40 CNC lathes and machining centers, and 17 sets of heat treatment equipment. After moving to the new facility in 2023, the company added a fully automatic heat treatment line.



Custom samples take 10–30 days. Standard products can be shipped within 10–15 days, while custom orders take 20–30 days. Repeat orders can be completed in a shorter time.

product-800-800



Key Parameters



Parameter

Value

Material

HT250 / QT450-10 ductile iron

Fit models

50–220 hp tractors, combine harvesters, rotary tillers

Machining accuracy

Hole position IT7–IT8, flatness ≤0.05 mm

Lubrication

Splash lubrication + forced oil channels

Working temperature

-30°C to 120°C

Seal setup

Embedded oil seal groove, anti-leak structure
