The Robot Joint Spindle is a core rotating part used in multi-joint industrial robots, collaborative robots, and robotic arms. Materials include 42CrMo, 20CrMnTi, and GCr15 bearing steel. High-strength alloy structural steel is precision forged and ground. The finished Robot Joint Spindle has good bending strength and fatigue resistance.

product-800-800



Joint Motion and Accuracy



Robot joints need to move quickly and stop at the required position during repeated operation. Dynamic balance is controlled during machining to keep joint movement smooth and positioning accurate. Heat treatment hardness is HRC30 to 60, with treatment divided by section. Radial runout tolerance is ≤0.01 mm, and coaxiality accuracy is ≤0.01 mm. Surface roughness reaches Ra≤0.8 μm.



Rated torque is 50 to 3000 N·m, and applicable speed is up to 5000 r/min. The working temperature range is -30°C to 120°C. Surface treatment options include blackening, phosphating, hard chrome plating, and anti-rust treatment. Shaft journals, splines, and mounting faces are precision machined. The part has good wear and impact resistance and can be used for high-frequency reciprocating motion and heavy-load reversing.



Applications include handling robots, welding robots, assembly robots, six-axis industrial robots, collaborative robots, robotic arm joints, and automated rotating mechanisms.



Machines and Delivery



The factory has more than 200 wire-cutting machine sets. More than 40 CNC lathes, CNC machines, and machining centers are also in use. Seventeen sets of heat treatment equipment are used for hardening. A fully automatic heat treatment production line was put into operation after the factory move.



Custom samples take 10 to 30 days. Standard products are shipped in 10 to 15 days. Custom orders take 20 to 30 days. Repeat orders can be completed faster. Buyers ordering the Robot Joint Spindle usually ask about radial runout first, because excessive runout can appear as positioning error at the end of the robotic arm.



Key Parameters



Parameter

Value

Material

42CrMo, 20CrMnTi, GCr15 bearing steel

Heat treatment hardness

HRC30–60 (zoned treatment)

Radial runout tolerance

≤0.01 mm

Coaxiality accuracy

≤0.01 mm

Rated torque

50–3000 N·m

Applicable speed

≤5000 r/min
