The Linear Guide Bushing is used in CNC machine tools, precision slide tables, and automated linear motion mechanisms. Materials include wear-resistant cast iron, tin bronze, 40Cr alloy steel, and powder metallurgy wear-resistant materials. High-wear alloy materials are precision machined. The finished Linear Guide Bushing is used as a guide and support bushing.

product-800-800



Bore, Clearance, and Slide



A guide bushing that sticks or wears unevenly can affect positioning accuracy. Inner bore dimensions and fit clearance are controlled during machining. The material and surface finish provide wear resistance, anti-friction performance, and resistance to seizing. Linear movement remains smooth without jamming.



Inner diameter tolerance reaches IT5 to IT7. Cylindricity is ≤0.005 mm. Inner bore surface roughness is Ra≤0.4 to 0.8 μm. Straightness is ≤0.01 mm/100 mm. Working temperature ranges from -20°C to 120°C. Fit clearance is 0.01 to 0.05 mm.



Surface treatment options include inner bore hardening, phosphating, hard chrome plating, and anti-rust treatment. Custom production is available according to guide size. Applications include CNC lathes, machining centers, precision slide tables, grinders, and automated linear guide mechanisms.

product-800-800



Testing and Buyer Questions



The factory has six sets of testing equipment, including a metallographic microscope, spectrometer, and ultrasonic flaw detector. These are used to check material composition and internal defects. Customers can request 100% inspection before packing. Third-party inspection is also welcome.



The company provides a warranty and accepts custom drawings. Buyers ordering the Linear Guide Bushing usually ask about fit clearance first, because excessive clearance can allow the slide to move out of position, while insufficient clearance can cause the bushing to seize as the machine temperature rises.



Key Parameters



Parameter

Value

Material

Wear-resistant cast iron, tin bronze, 40Cr alloy steel, powder metallurgy wear-resistant material

Inner diameter tolerance

IT5–IT7

Cylindricity

≤0.005 mm

Inner bore surface roughness

Ra≤0.4–0.8 μm

Straightness

≤0.01 mm/100 mm

Fit clearance

0.01–0.05 mm
